Tazón automático de bebida
The Automatic Cattle Drinking Bowl provides livestock with a continuously available water supply through an internal automatic float valve. The 3.0-liter cast iron basin provides a stable drinking point, while the stainless steel cover shields the internal mechanism from direct livestock contact and contamination.
El cuenco mide 295 × 262 × 155 mm and uses a 1/2″ threaded water inlet. Its operating pressure range of 0.1–0.4 MPa suits commonly used farm water supply systems within this specified range.
The cast iron construction provides a solid bowl structure for livestock areas, while the bottom drain stopper allows operators to remove accumulated dirt and feed residue during routine cleaning. The design can serve cattle and horses as well as smaller livestock such as sheep and dogs.
Especificaciones técnicas
| Especificación | Detalles |
| Código de producto | 202201 |
| Tipo de producto | Automatic float water bowl |
| Material del cuenco | Hierro fundido |
| Material de la cubierta | Acero inoxidable |
| Dimensiones (Largo × ancho × alto) | 295 × 262 × 155 milímetros |
| Capacidad | 3.0 Litros |
| Acabado superficial | Recubrimiento en polvo verde |
| Tipo de mecanismo | Internal Automatic Float Valve Assembly |
| Entrada de agua | 1/2″ Threaded Inlet |
| Presión de funcionamiento recomendada | 0.1–0,4 MPa (1.0–4,0 barras) |
| Ganado aplicable | Ganado, caballos, Oveja, Perros |
Características clave
- Cast iron bowl construction: Provides a rigid basin structure for regular livestock use.
- Internal float valve: Automatically controls the water level as animals consume water.
- Stainless steel protective cover: Shields the float assembly from direct contact with livestock and helps limit contamination of the mechanism.
- 3-capacidad de litro de agua: Provides a defined water volume within the bowl between replenishment cycles.
- Bottom drain stopper: Allows operators to empty the bowl and remove dirt or feed residue during cleaning.
- 1/2″ entrada roscada: Provides a standard threaded connection for integration with a suitable farm water supply line.
- Defined pressure range: Designed for water supply systems operating at 0.1–0.4 MPa.
Aplicaciones agrícolas
The bowl is intended for livestock housing areas where animals require regular access to drinking water. It can be used in cattle pens, instalaciones para caballos, sheep housing areas, and suitable dog facilities.
Para operaciones ganaderas, the bowl can serve as an individual drinking point within a pen or housing area. The automatic float mechanism reduces the need for manual water replenishment.
The same bowl design can also suit sheep and horses where the 3-liter capacity and physical dimensions match the animal group and installation location. En la práctica, operators should position the bowl where animals can access it comfortably while keeping the surrounding area suitable for routine cleaning.
Consejos de instalación
Install the bowl on a stable and appropriately supported surface within the livestock housing area. el 1/2″ threaded inlet should connect securely to a compatible water supply line.
Before regular operation, check the water supply pressure and keep it within the specified 0.1–0.4 MPa range. Después de la instalación, inspect the float mechanism to confirm that the valve opens and closes correctly as the water level changes.
Position the bowl where operators can reach the bottom drain stopper for routine cleaning. The installation should also provide enough working space to remove and clean the bowl and stainless steel cover.
Mantenimiento & Consejos de limpieza
Inspect the bowl regularly for feed residue, estiércol, y otras contaminaciones. Use the bottom drain stopper to empty the bowl before cleaning the basin.
Clean the cast iron basin and stainless steel cover according to the farm’s normal livestock hygiene procedures. Check the float assembly periodically for dirt or obstruction that could affect automatic water-level control.
Durante el mantenimiento de rutina, inspect the threaded water inlet and surrounding connection for leakage. If the float mechanism does not maintain the expected water level, stop using the bowl until the cause has been identified and corrected.
Preguntas más frecuentes
Does the bowl require a specific water pressure?
La presión de funcionamiento recomendada es 0.1–0,4 MPa (1.0–4,0 barras).
¿Qué tipo de conexión de agua utiliza??
The bowl has a 1/2″ threaded water inlet.
¿Qué animales pueden utilizar este bebedero??
The specified applications include ganado, caballos, oveja, y perros.
