Bevitore di maiali della valvola del morso
The Bite Valve Pig Drinker is designed for nursery and grower pigs that require a dependable water source throughout the production cycle. The bite-operated mechanism releases water when activated by the pig, helping maintain water availability while limiting unnecessary spillage.
Its compact body and standard 1/2″ threaded connection allow easy integration into common sistemi di abbeveraggio per suini. Il bevitore è disponibile in entrambi 201 acciaio inossidabile e 304 stainless steel options to suit different farm environments and budget requirements.
Per le migliori prestazioni, proper installation height, angle, and water pressure should match the age and weight of the animals.
Specifiche tecniche
| Articolo | Specifiche |
| Prodotto n. | 100102 |
| Materiale | 201 Acciaio inossidabile / 304 Acciaio inossidabile |
| Lunghezza | 73 mm |
| Dimensione filettatura | 1/2" Filo |
| Dimensioni del corpo | 1/2" Corpo |
| Pressione dell'acqua consigliata | 0.15–0,3MPa (22–44 PSI) |
| Recommended Water Flow Rate | 1.0–1.2 L/min |
| Suitable Pig Type | Suini della scuola materna |
| Peso del maiale consigliato | 15–30 chilogrammi |
| Altezza di installazione consigliata | 25–35 cm (10″–14″) |
| Angolo di installazione consigliato | 30° Downward |
| Suini consigliati per abbeveratoio | 8–12 maiali |
Caratteristiche principali
- Stainless steel construction for long service life
- Bite valve design encourages natural drinking behavior
- Moderate flow rate suitable for nursery-stage pigs
- Compact body design simplifies installation in nursery pens
- Compatible with commonly used pig drinking systems
- Helps reduce unnecessary water wastage compared with unrestricted water outlets
- Adatto per nuove installazioni e progetti di sostituzione
Applicazioni agricole
This drinker is typically installed in:
- Recinti per maialini
- Weaner accommodation areas
- Automatic drinking lines
- Piglet transition housing
- Impianti di produzione di suini commerciali
In pratica, the recommended capacity of 8–12 pigs per drinker helps maintain adequate access to water while avoiding excessive competition within the pen.
The unit is particularly suitable for operations seeking a dedicated drinking solution for pigs in the 15–30 kg weight range.
Suggerimenti per l'installazione
Correct installation helps ensure consistent performance.
- Install the drinker at a height of 25–35 cm from floor level.
- Position the unit at a 30° downward angle.
- Maintain water pressure within the recommended range of 0.15–0.3 MPa.
- Flush supply lines before installation to remove debris.
- Check connections carefully to prevent leakage.
Nella maggior parte degli allevamenti, adjusting drinker height as pigs grow helps maintain comfortable drinking access throughout the nursery stage.
Manutenzione & Consigli per la pulizia
Routine maintenance supports reliable operation and water quality.
Le pratiche consigliate includono:
- Inspect valve movement regularly.
- Remove dirt or mineral deposits if present.
- Check water flow periodically.
- Inspect threaded connections during routine barn maintenance.
- Flush drinking lines to reduce sediment accumulation.
Regular inspection helps identify wear before it affects drinking performance.
Domande frequenti
Per quale taglia di maiale è progettato questo abbeveratoio??
It is designed for nursery pigs weighing approximately 15–30 kg.
Quanti maiali possono condividere un abbeveratoio?
The recommended capacity is 8–12 pigs per drinker.
Quale materiale di acciaio inossidabile è disponibile?
Both 201 acciaio inossidabile e 304 sono disponibili versioni in acciaio inox.
