Bevitore di capezzoli per maiali ingrassati
Efficient water supply is an important part of modern pig production. This Nipple Drinker for Fattening Pigs is designed specifically for use in dry-wet feeding equipment, where water availability directly influences feed intake and feeding behavior.
The compact body allows easy installation inside feeder compartments while maintaining adequate flow for growing and finishing pigs. Prodotto da entrambi 201 O 304 acciaio inossidabile, the drinker provides good durability in demanding livestock environments.
Specifiche tecniche
| Articolo | Specifiche |
| Prodotto n. | 101129 |
| Materiale | 201 Acciaio inossidabile / 304 Acciaio inossidabile |
| Lunghezza | 60 mm |
| Connessione filettata | 3/8″ Filettatura femmina |
| Dimensioni del corpo | 1/2" Corpo |
| Pressione dell'acqua consigliata | 0.15–0,25MPa (22–36 PSI) |
| Portata consigliata | 1.0–2.0 L/min |
| Applicazione | Dry-Wet Pig Feeders |
Caratteristiche principali
- Compact design for feeder-mounted installation.
- Stainless steel construction suitable for livestock environments.
- Moderate water flow helps support efficient feed and water consumption.
- Female thread connection simplifies integration with feeder assemblies.
- Compatible with many dry-wet feeding configurations commonly used in commercial pig farms.
- Designed for continuous operation under recommended pressure conditions.
Applicazioni agricole
- Dry-wet feeders for growing pigs
- Dry-wet feeders for finishing pigs
- Impianti di produzione di suini commerciali
- Automatic feeding systems requiring integrated water access
- New barn construction and feeder replacement projects
Suggerimenti per l'installazione
- Install the nipple drinker securely into the designated feeder mounting position.
- Maintain water pressure within the recommended range of 0.15–0.25 MPa (22–36 PSI).
- Flush water lines before installation to remove debris.
- Check all threaded connections for leaks before placing the feeder into operation.
- Verify that water flow remains within the recommended range after installation.
Manutenzione & Consigli per la pulizia
- Check the valve movement periodically.
- Remove mineral deposits if water quality causes scaling.
- Inspect connections for leakage during routine barn maintenance.
- Flush supply lines when cleaning feeding systems.
- Replace worn components if flow performance decreases over time.
Domande frequenti
Is this drinker designed for standalone water lines?
This model is primarily intended for installation in dry-wet pig feeders.
Quale pressione dell'acqua è consigliata?
La pressione operativa consigliata è 0,15–0,25 MPa (22–36 PSI).
What flow rate does the drinker provide?
The recommended flow rate is 1.0–2.0 L/min.
