2.5L bovini automatici
The 2.5L Automatic Cattle Waterer is a cast iron drinking bowl designed for cattle, mucche, e cavalli. The bowl uses a cast iron paddle lever connected to a vertical water valve, allowing the animal to activate water flow through direct contact with the paddle.
The top-mounted 1/2″ female threaded inlet keeps the water connection positioned above the bowl. The 2.5-liter basin provides a compact drinking point for livestock pens, while the green powder-coated surface provides the specified surface finish for farm use.
Specifiche tecniche
| Specifiche | Dettagli |
| Codice prodotto | 201211 |
| Descrizione | Cast Iron Nipple-Paddle Water Bowl |
| Materiale della ciotola | Ghisa pesante |
| Dimensioni (L x P x A) | 280 × 230 × 160 mm |
| Capacità | 2.5 Litri |
| Finitura superficiale | Green Powder Coating |
| Tipo di meccanismo | Cast Iron Paddle Lever with Top Vertical Water Valve |
| Collegamento ingresso acqua | 1/2″ Top Female Threaded Connection |
| Pressione operativa consigliata | 0.15–0.45 MPa (1.5–4.5 Bar) |
| Portata dell'acqua | 9.0–13.0 L/min at 0.3 MPA |
| Bestiame applicabile | Bestiame, Mucche, Cavalli |
Caratteristiche principali
- Top-mounted water connection: The inlet sits on top of the bowl, helping protect the connection from direct animal contact.
- Cast iron paddle mechanism: The heavy paddle lever provides direct mechanical operation of the water valve.
- Powder-coated surface: The green powder coating provides the specified surface finish for livestock housing environments.
- Deep basin: The bowl provides a 2.5-liter drinking volume and helps contain water around the drinking point.
- Compact construction: IL 280 × 230 × 160 mm dimensions suit individual drinking points in cattle and horse pens.
Applicazioni agricole
This automatic cattle waterer is commonly used in cattle housing, cow pens, and horse facilities where an individual automatic drinking point is required.
The bowl can also be used for applicable livestock listed in the specifications. In pratica, installers should position the drinking bowl where animals can reach the paddle naturally while keeping the water connection protected from direct impact.
Suggerimenti per l'installazione
Install the bowl on a rigid and level mounting surface suitable for the livestock housing structure. Connect the water supply to the 1/2″ top female threaded inlet and check the connection for leakage before placing animals into the pen.
Maintain the recommended operating pressure of 0.15–0.45 MPa (1.5–4.5 Bar). Dopo l'installazione, operate the paddle manually to confirm that the valve opens and closes correctly.
Manutenzione & Consigli per la pulizia
Clean the basin regularly to remove feed residue, letame, e altri contaminanti. The bowl design includes a deep basin, so routine cleaning helps maintain suitable drinking-water conditions.
During maintenance, inspect the paddle lever and water valve for smooth operation. Check the threaded inlet and water connection for leakage, particularly after installation or pipework adjustments.
FAQ
Q: Quale pressione dell'acqua richiede questa ciotola??
UN: The recommended operating pressure is 0.15–0.45 MPa (1.5–4.5 Bar).
Q: What type of water connection does it use?
UN: It uses a 1/2″ ingresso acqua filettato femmina superiore.
Q: Which animals can use this waterer?
UN: Le applicazioni specificate includono il bestiame, mucche, e cavalli.
